General |
Host Bus Interface |
PCIe 3.0 x2 |
Size (Height x Width x Depth) |
26.37 mm x 45.38 mm x 75.7 mm |
Operating Temperature |
0°C to 40°C (32°F to 104°F) |
Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
Relative Humidity |
5% to 95% RH |
Warranty |
3 Years |
Notes |
The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) |
Network |
IEEE Specification Compliance |
- IEEE 802.3x Flow Control
- IEEE 802.3u Fast Ethernet
- IEEE 802.3ab Gigabit Ethernet
- IEEE 802.3bz 2.5Gbps / 5Gbps Ethernet
- IEEE 802.3an 10Gbps Ethernet
|
Data Transfer Rates |
10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps |
Supported Features |
- 9 KB Jumbo Frame
- TCP/UDP/IP Checksum Offloading
- Auto-negotiation between 100Mb/s, 1Gb/s, 2.5Gb/s, 5Gb/s, and 10Gb/s
- TCP Segmentation Offload (TSO)
- Large Send Offload (LSO)
- Receive Side Scaling (RSS)
- Generic Receive Offload (GRO)
- Generic Segmentation Offload (GSO)
|
Compatibility |
Applied Models |
- 22 series:RS422+, DS1522+
|
