Model | |
---|---|
Brand | Western Digital |
Series | Blue |
Model | WDS200T2B0B |
Device Type | Internal Solid State Drive (SSD) |
Used For | Consumer |
Details | |
Form Factor | M.2 2280 |
Capacity | 2TB |
Memory Components | 3D NAND |
Interface | SATA III |
Performance | |
Max Sequential Read | Up to 560 MBps |
Max Sequential Write | Up to 530 MBps |
4KB Random Read | Up to 95,000 IOPS |
4KB Random Write | Up to 84,000 IOPS |
MTTF | Up to 1.75M hours |
Environmental | |
Power Consumption (Idle) | 56mW (Slumber)
5-12mW (DEVSLP) |
Power Consumption (Active) | 60mW (Avg. Active Power)
3,000mW (Max Read Operating) 3,800mW (Max Write Operating) |
Operating Temperature | 0°C ~ +70°C |
Storage Temperature | -55°C ~ +85°C |
Max Vibration Resistance | Operating: 5.0 gRMS, 10-2000 Hz
Non-operating: 4.9 gRMS, 7-800 Hz |
Dimensions & Weight | |
Height | 2.23mm |
Width | 22.00mm |
Depth | 80.00mm |
Weight | 7.00g |
