Capacity | 2TB |
Features |
• Silicon Motion 3D TLC Flash controller • StaticDataRefresh technology ensures data integrity • SLC caching accelerates burst performance • Device Sleep mode (DEVSLP) supported for ultra low idle power consumption • SATA 3.0 (6Gb/s) interface (backwards compatible with SATA 2.0 (3Gb/s) and SATA 1.0 (1.5Gb/s)) • Supports Security Erase • TRIM support (OS/driver support required) • High-reliability 3D TLC NAND flash • S.M.A.R.T. support • Temperature sensor |
Performance |
• Sequential Read: Up to 550MB/s • Sequential Write: Up to 505MB/s • Random Read: Up to 74K IOPS (4K block size) • Random Write: Up to 67K IOPS (4K block size)** |
Endurance |
• TBW: Up to 1250TB • DWPD: 0.57 |
Security |
• User selectable ATA password support • Secure Erase support |
Reliability |
• MTBF: 1.5 million device hours* • Low Density Parity Check (LDPC) ECC • Static and dynamic wear leveling • Uncorrectable Bit Error Rate: =1 sector per 1016 bits read |
Electrical |
• +5VDC (±5%) power supply • Power Consumption: up to 2.1W (Active), 0.09W (Idle) |
Environmental |
• Operating temperature: 0-70°C • Non-Operating temperature: -40-85°C • Operating humidity: 5-95% relative • Shock: 1500G/0.5ms • Vibration: 2-500Hz, 3.1G |
RoHS Compliant | |
TAA Compliant | |
Note: As used for storage capacity, one gigabyte (GB) = one billion bytes. Total accessible capacity varies depending on operating environment *Based on Telcordia SR-332 reliability prediction procedure. **Max sequential speeds measured using ATTO 2.46 at queue depth 10. Max IOPS measured using IOMeter 1.1 at queue depth 32 |
