Chipset |
Renesas uPD720201 |
Supports UASP function (with Windows 10 and 8 native USB 3.0 Host driver only) |
Supports data transfer rate up to 5Gb/s and backward compatible with USB 2.0/1.1 devices |
Compliant with Universal Serial Bus 3.0 Specification |
Compliant with PCI Express Base Specification, Revision 2.0 |
Supports per port over-current protection |
Dimensions |
2.76" (W) x 0.79" (D) x 4.72" (H) |
Weight |
0.12lbs |
Connectors |
4x 9-pin, Type A, USB 3.0, Female, External |
1x 15-pin, SATA power connector |
Environmental conditions |
Operating temperature |
32 to 120 degrees F |
Storage temperature |
-4 to 140 degrees F |
Operating humidity |
20% to 80% RH |
Storage humidity |
10% to 90% RH |
Certifications/Standards |
FCC, CE, RoHS |
Warranty |
Lifetime limited |
Country of origin |
China |
