GENERAL |
Brand |
Mushkin Enhanced |
Series |
Source HC |
Model |
MKNSSDHC4TB |
Type |
7mm Internal Solid State Drive (SSD) |
Used For |
Consumer |
UPC |
846651030719 |
PHYSICAL |
Form Factor |
2.5" |
Capacity |
4TB |
Interface |
SATA 6Gb/s |
Controller |
Phison S12 |
Height |
7mm |
Width |
69.85mm |
Depth |
100.45mm |
Weight |
50g |
PERFORMANCE |
Max Sequential Read |
Up to 555MB/s |
Max Sequential Write |
Up to 535MB/s |
4KB Random Read |
Up to 97,000 |
4KB Random Write |
Up to 89,000 |
Seek Time |
<0.1ms |
TBW |
1250 |
MTBF |
1,500,000 hours |
FEATURES |
FEATURES |
MEDS (Mushkin Enhanced Data-protection Suite) ensures valuable data is protected |
- Built-in LDPC ECC provides the most-powerful error correction method in use today |
- Internal flash RAID provides additional error correction capability |
- Data shaping increases endurance |
- StaticDataRefresh ensures data integrity |
- Global wear-leveling evens program/erase counts across data blocks to extend lifespan |
SLC caching accelerates burst performance |
Device Sleep mode (DEVSLP) supported |
Supports Security Erase |
TRIM support (OS/driver support required) |
High-reliability 3D TLC NAND flash |
S.M.A.R.T. support |
User-upgradeable firmware |
Temperature sensor |
RoHS, FCC, CE |
Power Consumption (Idle): 0.08W |
Power Consumption (Active): 2W |
Max sequential speeds and IOPS measured using CrystalDiskMark 6.0.2 x64 |
ENVIRONMENTAL |
Operating Temperature |
0°C-70°C |
Storage Temperature |
-40°C-85°C |
Max Shock Resistance |
1500G |
Power Supply |
5V DC |
