- Aluminum Frame, designed for heavy-duty purpose
- Support SAS I/II/III and SATA I/II/III Hard Drives
- High Performance Transfer Rate up to 12Gb/s
- Integrative shaping aluminum design for quickest heat sink
- Aluminum front bezel with metal key lock mechanism for double safety
- Removable fan cover for easy maintenance
- Multi-functional LED Indication
- Support Hot-Swap & RAID Configuration (need an additional RAID controller)
- Low-noise Design with Fan-speed Control
- 14TB Hard Drives Compatible
Model Number | BPN-SEA230HD-BLACK |
RoHS Compliance | Yes |
Standard Drive Bays |
Hotswap 3.5": 3 5.25" Drives: 2 |
Hotswap HDD Type: | 3.5" SAS I/II/III & SATA I/II/III |
Indicators | Blue for Power on/ Purple for HDD Access |
Security | Key Lock |
Material of Front Bezel | Aluminum |
Material of Handle | Aluminum |
Material of Main Chassis | Aluminum |
Color of Front Bezel | Black/ Blue/ Red/ Silver |
Color of Main Chassis | Black |
Cooling Fan | 1x70mm |
Ordering Information (Part Number) |
Black Handle:BPN-SEA230HD-BLACK Blue Handle:BPN-SEA230HD-BLUE Red Handle:BPN-SEA230HD-RED Silver Handle:BPN-SEA230HD-SILVER |
Dimensions (WxHxD) |
5.71" x 3.35" x 7.64" 145.0 mm x 85.1 mm x 194.1 mm |
