Create more space for hard drive with hot-swap capability, BPU-230SATA series supports RAID 1/0/1+0/5 configuration for high performance or redundancy data application. Aluminum construction provides light weight but strong stability and extra 70mm fan keep hard drive at maximum performance.
High density multi-disk storage backplane that allows multiple 3x3.5" SAS/SATA hard drives to be mounted into 2 standard 5.25". Aluminum construction provides best heat dissipation required for high performance SAS/SATA drives, is designed with excellent front to back vent airflow. Applications: Digital Audio Editing,Video Editing (SD or HD),Security System,SOHO SMEs With Limit HDD Tray and Data Protection or Disk-to-Disk Backup
- Stylish aluminum color handle and heat-sink body
- Support Hot-Swap & RAID Configuration (need an additional RAID controller)
- Aluminum Design with Conductive Dissipation Grooves
- Power, fan and high temperature LED indicators
- High Performance Transfer Rate up to 6.0 Gb/s
- Support 2.5"/3.5" SAS I/II & SATA I/II/III HDDs
- Equipped with Fan Speed Control Switch
- 6TB Hard Drive Compatible
Model Number | BPU-230sata |
RoHS Compliance Version | Yes |
Standard Drive Bays |
Hotswap 3.5": 3 5.25" Drives: 2 |
Hotswap HDD Type: | 3.5" SAS I/II & SATA I/II/III |
Indicators | Power, HDD, fan, and high temperature |
Material of Front Bezel | Aluminum |
Material of Handle | Aluminum |
Material of Main Chassis | Aluminum Design with Conductive Dissipation Grooves |
Color of Front Bezel | Black/ Blue/ Red/ Silver |
Color of Main Chassis | Black |
Package Content | SATA Cable Included (3pcs) |
Cooling Fan | 1x70mm |
Ordering Information (Part Number) |
Black Tray:BPU-230SATA-BLACK Blue Tray:BPU-230SATA-BLUE Red Tray:BPU-230SATA-RED Silver Tray:BPU-230SATA-SILVER Lockable Tray:BPU-230SATA-BPL |
Dimensions (WxHxD) |
5.75" x 3.39" x 8.22" 146.0 mm x 86.1 mm x 208.8 mm |
