HEATSINK SPECIFICATION | |
---|---|
Dimension ( with fan ) | L97 mm x W97 mm x H47 mm |
Compatibility | Intel 1151/1150/1155/1156 AMD AM2/AM2+ AM3/AM3+ (LGA2011 Not Supported, AM4 support requires additional AM4 kit ) |
Weight ( with fan ) | 357 g |
Weight ( without fan ) | 295 g |
Heat pipes | 6mm heatpipe x 4 units |
Fin | T = 0.4 mm ; Gap = 1.2 mm |
Fin Pcs | 57 pcs |
Copper Base | C1100 Pure copper nickel plated |
RAM Height Limit | Limitless |
TDP | 100 W |
FAN SPECIFICATION | |
Dimension | L92 mm x W92 mm x H15 mm |
Weight | 62 g |
Rated Speed | 600 ~ 2500 RPM ±10 % |
Noise Level | 30 dBA |
Air Flow | 40.5 CFM |
Air Pressure | 2.8 mmH2O |
Ampere | 0.2 A |
