D-300-PFS, Black Bezel, 2x 5.25", 6x 3.5" Drive Bays, No PSU, ATX, Black, 3U Chassis
Quantity:
- SKU: 13018450
- Manufacturer: ISTARUSA
- MPN: D-300-PFS
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$150.64
D-300-PFS, Black Bezel, 2x 5.25", 6x 3.5" Drive Bays, No PSU, ATX, Black, 3U Chassis
The 3U industrial rackmount chassis D Storm D-300-PFS. It features two 5.25 and six 3.5 bays for high density storage application. D-300-PFS backplane supports 7 full-length add-on cards. Optional Aluminum Body reduces total chassis weight and also provides enhanced thermal cooling solution provide your system with maximum flexibility and performance.
D-300-PFS 3U Compact Stylish Rackmount Chassis Front-mounted ATX Power Supply
- Front Mount ATX Power Supply
- Front Access USB2.0 x2
- 80mm x1, 60mm x1 Cooling Fan
- Removable Air Filter
- Power and HDD LED
- Power and Alarm Reset Switch
- Optional Aluminum Chassis
| Model Number | D-300-PFS |
| RoHS Compliance | Yes |
| Form factor | 3 U |
| Standard Drive Bays | 3.5" Drives: 1
3.5" Drive (internal): 5 5.25" Drives: 2 |
| Indicators | Power, HDD, Temperature, Fan (Fan/Temp require sensor board TC-ISF08 ) |
| Switches | Power ON/OFF, System & Alarm Reset |
| Expansion Slots | 7 |
| Security | Front Bezel |
| Material of Front Bezel | Plastic |
| Material of Handle | SECC Zinc-Coated Steel |
| Material of Main Chassis | 1.2mm SECC Zinc-Coated Steel (Japan Made) |
| Color of Front Bezel | Black |
| Color of Main Chassis | Black |
| Front Connector | Front USB 2.0 x 2 Connector |
| Air Filter | Removable & Washable |
| Motherboard Size | 12 x 9.6 (ATX, microATX) |
| Cooling Fan | 1x60mm, 1x80mm |
| Optional Fan: | 60mm x1, 80mm x3 (bracket DD-FANGUARD-8 required) |
| Dimensions (WxHxD) | 19.00" x 5.25" x 20.80"
482.6 mm x 133.3 mm x 528.3 mm |
| Notes | - supports standard ATX power supply length up to 160mm. |
