The CyberPower BP36V60ART2U rack/tower convertible Extended Battery Module (EBM), which extends battery runtimes during power outages, is designed for Smart App Online UPS systems OL1000RTXL2U and OL1500RTXL2U. This EBM takes 2U of rack space and can be installed in a rack or tower configuration to match the UPS form factor. It also has a built-in battery charger, providing Fast Charge Technology to quickly restore the backup power supply to full capacity.
Up to ten EBMs can be added to the UPS, and the module's DC plug-and-play power connectors allow for daisy-chaining additional EBMs to a UPS system. The BP36V60ART2U typically has a UPS charging time of five hours, regardless of whether one or ten EBMS are installed, and comes with a three-year warranty.
- Output: 36V/60A
- Recharge time: 4 hours
- Battery type & quantity: 12V/9AH (6)
- Form factor: Rack/Tower
- Hot swappable: Yes
- Fast Charge Technology: Yes
- Warranty: 3 year
General | |
Voltage | 36V |
Amperage | 60A |
Battery | |
Battery Type | Sealed Lead-Acid |
Battery Size | 12V/9Ah |
Hot-Swappable | Yes |
Battery Quantity | 6 |
User Replaceable | Yes |
Replacement Battery | (1) RB1290X3R & (1) RB1290X3L |
Typical Recharge Time | 4 hours |
Built-in Charger | Yes |
Expansion Ready (Daisy-Chain) | Yes |
Physical | |
Rack Size | 2U |
Enclosure Contruction | Steel |
Mounting Hardware | Included |
Dimensions – W×H×D (in) | 17 × 3.5 × 16.9 inches |
Dimensions – W×H×D (mm) | 550 × 240 × 590 mm |
Weight (lbs) | 50.6 lbs |
Weight (kg) | 22.9 kg |
Shipping Dimensions – W×H×D (in) | 21.65 × 9.45 × 23.23 inches |
Shipping Weight (lbs) | 65.34 lbs |
Shipping Weight (kg) | 29.6 kg |
Environmental | |
Operating Temperature | 32 – 104 °F (0 – 40 °C) |
Operating Humidity | 0 – 90% (non-condensing) |
Operating Elevation | 0 – 10,000 ft (0 – 3,000 m) |
Storage Temperature | 5 – 113 °F (-15 – 45 °C) |
Storage Relative Humidity | 0 – 95% (non-condensing) |
Storage Elevation | 0 – 50,000 ft (0 – 15,000 m) |
Certifications | |
Safety |
UL1778 CSA C22.2 NO.107.3-05 FCC DOC Class A |
Environmental | RoHS Compliant |
Warranty | |
Product Warranty | 3 Years Limited |
