- Output: 48V/60A
- Recharge time: 6 hours
- Battery type & quantity: 12V/7AH (8)
- Weight: 55.8 lbs.
- Form factor: Rack/Tower
- Hot swappable: Yes
- Warranty: 3 year
General | |
Voltage | 48V |
Amperage | 60A |
Battery | |
Battery Type | Sealed Lead-Acid |
Battery Size | 12V/7Ah |
Hot-Swappable | Yes |
Battery Quantity | 8 |
User Replaceable | Yes |
Built-in Charger | Yes |
Typical Recharge Time | 6 hours |
Replacement Battery | RB1270X4H |
Replacement Battery Cartridge Quantity | 2 |
Physical | |
Color | Black |
Rack Size | 2U |
Dimensions – W×H×D (in) | 17.1 x 3.4 x 16.2 |
Weight (lbs) | 55.8 |
Shipping Dimensions – WxHxD (in) | 22.1 x 10.8 x 20.9 |
Shipping Weight (lbs) | 63.7 |
Environmental | |
Operating Temperature | 32 – 95 °F (0 – 35 °C) |
Operating Humidity | 0 – 95% (non-condensing) |
Storage Temperature | 5 – 113 °F (-15 – 45 °C) |
Storage Relative Humidity | 0 – 95% (non-condensing) |
Maximum Operating Elevation | 10,000 ft (3,000 m) |
Maximum Storage Elevation | 50,000 ft (15,000 m) |
Certifications | |
Safety | CE, RCM, UL1778, cUL, FCC Class B, VCCI |
Environmental | RoHS Compliant |
Warranty | |
Product Warranty | 3 Years Limited |
