Extended Battery Module BP72V60ART2U, 72V/60A, Black, Tower/2U Rackmount Battery Pack
Quantity:
- SKU: 7248661
- Manufacturer: CYBERPOWER SYSTEMS
- MPN: BP72V60ART2U
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$1,064.95
Extended Battery Module BP72V60ART2U, 72V/60A, Black, Tower/2U Rackmount Battery Pack
The CyberPower BP72V60ART2U rack/tower convertible Extended Battery Module (EBM) for Smart App Online UPS systems OL2200RTXL2U, OL3000RTXL2U, and OL3000RTXL2UHV extends battery runtimes during power outages. This EBM takes 2U of rack space and can be installed as a tower to match the UPS form factor. It also has a built-in battery charger, providing Fast Charge Technology to quickly restore the backup power supply to full capacity.
Up to ten EBMs can be added to the UPS, and the module's DC plug-and-play power connectors allow for daisy-chaining additional EBMs to a UPS system. The BP72V60ART2U typically has a UPS charging time of 4 hours, regardless of whether one or ten EBMS are installed, and comes with a three-year warranty.
- Output: 72V/60A
- Recharge time: 5 hours
- Battery type & quantity: 12V/9AH (12)
- Weight: 96.8 lbs.
- Form factor: Rack/Tower
- Hot swappable: Yes
- Fast Charge Technology: Yes
- Warranty: 3 year
| General | |
| Voltage | 72V |
| Amperage | 60A |
| Battery | |
| Battery Type | Sealed Lead-Acid |
| Battery Size | 12V/9Ah |
| Battery Quantity | 12 |
| Hot-Swappable | Yes |
| User Replaceable | Yes |
| Replacement Battery Cartridge | RB1290X6B |
| Replacement Battery Cartridge Quantity | 2 |
| Typical Recharge Time | 4 hours |
| Built-in Charger | Yes |
| Expansion Ready (Daisy-Chain) | Yes |
| Physical | |
| Rack Size | 2U |
| Enclosure Contruction | Steel |
| Mounting Hardware | Included |
| Dimensions – W×H×D (in) | 17 × 3.5 × 23.6 inches |
| Dimensions – W×H×D (mm) | 433 × 88 × 600 mm |
| Weight (lbs) | 96.8 lbs |
| Weight (kg) | 43.9 kg |
| Shipping Dimensions – W×H×D (in) | 23.23 × 8.43 × 35.04 inches |
| Shipping Weight (lbs) | 115.94 lbs |
| Shipping Weight (kg) | 52.6 kg |
| Environmental | |
| Operating Temperature | 32 – 104 °F (0 – 40 °C) |
| Operating Humidity | 0 – 90% (non-condensing) |
| Operating Elevation | 0 – 10,000 ft (0 – 3,000 m) |
| Storage Temperature | 5 – 113 °F (-15 – 45 °C) |
| Storage Relative Humidity | 0 – 95% (non-condensing) |
| Storage Elevation | 0 – 50,000 ft (0 – 15,000 m) |
| Certifications | |
| Safety |
UL1778 CSA C22.2 NO.107.3-05 FCC DOC Class A |
| Environmental | RoHS Compliant |
| Warranty | |
| Product Warranty | 3 Years Limited |
