Compatibillity | |
Intel: | LGA1851 | LGA1700 |
AMD: | AM5 | AM4 |
PI | NNPI: | 245 | 219 |
TIM: | MX-6 (0.8 g) |
Warranty: | 6 Years |
Operating Ambient Temperature: | 0—40 °C |
Dimensions: | 104 (L) x 126 (W) x 159 (H) mm |
Weight: | 917 g |
Heatsink | |
Heatpipes: | 4x 6 mm Ø, Copper |
Fin Stack: | 59x 0.4 mm, Aluminium |
Fans | |
Fan: | 2x P12 PWM PST A-RGB |
Speed: | 200 - 2000 rpm, PWM Controlled (0 rpm below 5 % PWM) |
Bearing: | Fluid Dynamic Bearing |
Current | Voltage: | 0.11 A | 12 V DC |
Cable Lenght: | 200 mm + 80 mm Splitter Cable |
Connector: | 4-Pin PWM-Connector + 4-Pin Plug |
RGB
|
|
LEDs: | 12x A-RGB LEDs |
Current | Voltage: | 0.40 A | 5 V DC |
Cable Lenght: | 200 mm + 80 mm Splitter Cable |
Connector: | 3-Pin A-RGB-Connector + 3-Pin Plug |
Packaging | |
Width | 186 mm |
Height | 117 mm |
Length | 190 mm |
Weight | 1.26 kg |
