M-4160HD-ATX, Black HDD Handle, 16x 3.5" + 2x 2.5" Hotswap Bays, No PSU, ATX, Black, 4U Chassis
Quantity:
- SKU: 15088389
- Manufacturer: ISTARUSA
- MPN: M-4160HD-ATX
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$1,053.39
| Model Number | M-4160HD-ATX |
| RoHS Compliance | Yes |
| Form factor | 4 U |
| Standard Drive Bays |
2.5" Drive (internal): 1 Hotswap 2.5": 2 with T-C25HD (Opt.) Hotswap 3.5": 16 Slim 5.25" Optical: 1 |
| Hotswap HDD Type: | 3.5" SAS I/II/III & SATA I/II/III |
| Indicators | Power, HDD |
| Switches | Power, Reset |
| Supported PSU Type | Standard ATX (PS2) |
| Expansion Slots | 7 |
| Security | Key Lock |
| Material of Front Bezel | Aluminum with Steel |
| Material of Handle | Aluminum |
| Material of Main Chassis | Steel |
| Color of Front Bezel | Black |
| Color of Main Chassis | Black |
| Front Connector | 1x USB 3.0 |
| Motherboard Size | 12 x 9.6 (ATX, microATX, mini-ITX) |
| Cooling Fan | 3x120mm |
| Optional Fan: | 60mm x2 |
| Dimensions (WxHxD) |
19.00" x 6.92" x 22.85" 482.6 mm x 175.8 mm x 580.4 mm |
| Notes | - each hdd backplane (for 4 hard drives) requires two Molex power connectors from the power supply. |
