MAG A1000GL PCIE5 II, 80 PLUS Gold 1000W, Fully Modular, ATX Power Supply
Quantity:
- SKU: 18396042
- Manufacturer: MSI
- MPN: MAGA1000GLPCIE5II
- Availability: TEMPORARILY OUT OF STOCK
Starting At
$134.07
- ATX 3.1 ready, native dual-color PCIe CEM 5.1 connector
- Supports NVIDIA® GeForce RTX™ 40 series graphics cards
- Fully modular design, flat cables
- 80 PLUS Gold certified for high efficiency
- Active PFC design
- Protection with OVP / OCP / OPP / OTP / SCP / UVP
- 135 mm fluid dynamic bearing fan
- LLC half bridge topology with DC-to-DC module design
| Efficiency Rating | 80 PLUS Gold (up to 90%) |
| Modular | Yes (fully modular) |
| Fan Size | 135 mm |
| Fan Bearing | Fluid Dynamic Bearing |
| Dimensions (DxWxH) | 150 x 150 x 86 mm |
| PFC Type | Active PFC |
| Input Voltage Range | 100-240V~ |
| Power Watt | 1000W |
| Power Excursion | 2000W (*up to 200% of the PSU's rated power for 100μs) |
| Input Frequency Range | 50-60Hz |
| Protection | OCP / OVP / OPP / OTP / SCP / UVP |
| ATX (24 pin) | 1 |
| EPS (4+4 pin) | 2 |
| PCI-E 5.1 (16 pin) | 1 |
| PCI-E (6+2 pin) | 4 |
| SATA (15 pin) | 12 |
| PERIPHERAL (4 pin) | 4 |
| FDD (4 pin) | 1 |
