N6, Socket LGA 4189, 110mm Height, 270W TDP, Copper/Aluminum CPU Cooler

Quantity:
  • SKU: 13749952
  • Manufacturer: DYNATRON
  • MPN: N6
  • Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$32.16
Quantity:
N6, Socket LGA 4189, 110mm Height, 270W TDP, Copper/Aluminum CPU Cooler
The Dynatron N6 CPU cooler is designed for N6
CPU Support

Intel

CPU Socket

FCLGA 4189-4/5(Socket P4/P5 or P+)

Solution

3U Server and Up

Dimensions

128 x 91 x 110 mm

Weight

600 g

Material

Aluminum Stacked-fin with Heat Pipes directly contact CPU

Fan Dimension

80 x 38 mm

Speed

At Duty Cycle 0~20%: 800 ± 200 RPM
At Duty Cycle 50%: 1500 ± 10% RPM
At Duty Cycle 100%: 3000 ± 10% RPM

Rated Voltage

12V

Bearing

2 Ball Bearing

Power

At Duty Cycle 0~20%: 0.48 W
At Duty Cycle 50%: 0.84 W
At Duty Cycle 100%: 2.88 W

Air Flow

At Duty Cycle 0~20%: 13.67 CFM
At Duty Cycle 50%: 25.63 CFM
At Duty Cycle 100%: 51.26 CFM

Noise Level

At Duty Cycle 0~20%: 13.45 dBA
At Duty Cycle 50%: 27.1 dBA
At Duty Cycle 100%: 42.15 dBA

Air Pressure

At Duty Cycle 0~20%: 0.402 mm-H2O
At Duty Cycle 50%: 1.41 mm-H2O
At Duty Cycle 100%: 5.66 mm-H2O

Lead Wire Pin Out

Pin#1-Black(-)
Pin#2- Yellow(+)
Pin#3- Green(Tachometer/ Signal Output)
Pin#4- Blue (PWM)

Thermal Grease

Shin-Etsu 7762 Pre-printed
