Cooler Specification |
Socket compatibility |
Intel Xeon LGA4189 |
Height (without fan) |
165 mm |
Width (without fan) |
150 mm |
Depth (without fan) |
52 mm |
Weight (without fan) |
797 g |
Height (with fan) |
165 mm |
Width (with fan) |
150 mm |
Depth (with fan) |
78 mm |
Weight (with fan) |
957 g |
Material |
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating |
NSPR |
162 |
Max. TDP |
see NSPR |
Fan compatibility |
140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25 |
Scope of delivery |
- NF-A15 HS-PWM premium fan
- Anti-vibration pads and fan-clips for second NF-A15
- NT-H1 high-grade thermal compound (pre-applied)
- SecuFirm2™ mounting kit for LGA4189
- CPU carrier frame for LGA4189-4 (P4)
- NM-SMT5 Torx® T30 mounting tool
- Noctua metal case-badge
|
Warranty |
6 Years |
FAN Specification |
Model |
Noctua NF-A15 HS-PWM |
Bearing |
SSO2 |
Max. rotational speed (+/- 10%) |
1500 RPM |
Min. rotational speed (PWM, +/-20%) |
300 RPM |
Max airflow |
140,2 m³/h |
Max. acoustical noise |
24,6 dB(A) |
Input power |
1,56 W |
Voltage range |
12 V |
MTTF |
> 150.000 h |
