Heatsink Specifications | |
Dimension | L125 mm x W110 mm x H155 mm |
Weight | 730g |
Heat pipes | 6mm heatpipe x 6 units |
Copper Base | C1100 Pure copper nickel plated |
TL-C12C FAN Spec | |
Dimension | L120 mm x W120 mm x H25 mm |
Weight | 120g |
Rated Speed | 1550 RPM±10% (MAX) |
Noise Level | 25.6 dBA |
Air Flow | 66.17 CFM (MAX) |
Air Pressure | 1.53 mm H2O (MAX) |
Ampere | 0.20 A |
Connector | 4 Pin (PWM Fan connector) |
Bearing Type | S-FDB Bearing |
