Pure Base 501 DX, Tempered Glass, No PSU, ATX, White, Mid Tower Case
Quantity:
- SKU: 18582955
- Manufacturer: be quiet!
- MPN: BGW77
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$160.07
Pure Base 501 DX, Tempered Glass, No PSU, ATX, White, Mid Tower Case
LOOKING GOOD!
LOOKING GOOD!
Let it shine
Pure Base 501 DX White features ARGB LEDs on the case’s front and inside the case. That makes the PC case hit the sweet spot between ARGB illumination and elegant understatement the Pure Base 501 case series is known for. The front has been designed from scratch to match the illumination and make a statement in your room.
Pure Base 501 DX White is an impressively illuminated be quiet! ATX case with compact dimensions and high airflow for any application.
- High airflow intake front panel and top cover for maximum performance
- 3 preinstalled Pure Wings 3 140mm PWM fans for extraordinary air pressure
- Dynamic case front design with elegant ARGB lighting inside and outside of the case
- Generous space for high-end graphics cards and large coolers, despite compact footprint
- Optional vertical graphics card installation
- Water cooling ready for radiators up to 360mm
- USB 3.2 Gen. 2 Type C for best connectivity
- Side panel made of tempered glass
| General data | |
| Model | Pure Base 501 DX White |
| Color option | White |
| Motherboard compatibility | ATX / M-ATX / Mini-ATX |
| Case size excl. stands (L x W x H), (mm) | 450 x 231 x 449 |
| Case size incl. stands (L x W x H), (mm) | 450 x 231 x 463 |
| Volume (l) | 24.4 |
| PSU form factor | ATX PS/2 |
| Net weight (kg) | 7.2 |
| Expansion slots | 7 |
| Pre-installed fans | |
| Fan at top | 1x Pure Wings 3 140mm PWM |
| Fan at front | 1x Pure Wings 3 140mm PWM |
| Fan at side | - |
| Fan at rear | 1x Pure Wings 3 140mm PWM |
| Fan at bottom | - |
| Dimensions (L x W x H), (mm) | 140 x 25 x 140 |
| Fan speed at 100% PWM / 12V (rpm) | 1200 |
| Airflow at 100% PWM / 12V (CFM / m3/h) | 57.4 / 97.5 |
| Air Pressure at 100% PWM / 12V (mm H2O) | 0.96 |
| Noise level at 100% PWM / 12V (dB(A)) | 21.9 |
| Voltage range (V DC) | 5 - 13.2 |
| Input power (W) | 3.6 |
| Input current (A) | 0.06 |
| Connector | 4-pin PWM |
| Lifespan (h / 25°C) | 80,000 |
| Fan controller | - |
| Maximum fan installation | |
| Maximum fans | 6 |
| Top (mm) | 2x 140 / 2x 120 |
| Front (mm) | 2x 140 / 3x 120 |
| Side (mm) | - |
| Rear (mm) | 1x 140 / 1x 120 |
| Bottom (mm) | - |
| PSU shroud | - |
| Optional radiator installation | |
| Top (mm) | 120 / 240 |
| Front (mm) | 120 / 140 / 240 / 280 / 360 |
| Side (mm) | - |
| Rear (mm) | 120 / 140 |
| Bottom (mm) | - |
| PSU compatibility | |
| Maximum dimensions excl. bottom fan (mm) | 200 |
| Maximum dimensions incl. bottom fan (mm) | 180 |
| Graphics card | |
| HDD cage (in height of graphics card) installed (mm) | 368 |
| HDD cage (in height of graphics card) removed (mm) | 368 |
| Maximum PCIe slots with vertical graphics card (pcs.) | 5 |
| Drive bay capacity | |
| 5.25 bays (pcs.) | - |
| 3.5 slots (scope of delivery) | 2 |
| 3.5 slots (max.) | 2 |
| 2.5 slots (scope of delivery) | 5 |
| 2.5 slots (max.) | 5 |
| Cooling | |
| Max.construction height of CPU cooler unit (mm) | - |
| Airflow channel | - |
| Lighting | |
| LED illumination | - |
| LEDs (pcs.) | - |
| LED type | - |
| LEDs synchronizable with controller/motherboard | - |
| I/O Panel | |
| USB 3.2 Gen. 2 Type C | 1 |
| USB 3.2 Type A | 2 |
| USB 2.0 | - |
| HD Audio I/O | Mic + Audio |
| Qi charger / Quick Charging Option (W) | - |
| Insulation and damping | |
| Top panel insulation mats | - |
| Front panel insulation mats | - |
| Side panel insulation mats | √ |
| Anti-vibration decoupled HDD | √ |
| Anti-vibration decoupled fan | - |
| Anti-vibration decoupled PSU | √ |
| Anti-vibration decoupled motherboard-tray | - |
| Scope of delivery | |
| Screw set (Drives/Motherboard) | √ |
| Additional standoffs (pcs.) | 1 |
| SSD bracket for PSU shroud | - |
| LED strips (pcs.) | 2 |
| Cable ties (pcs.) | 12 |
| Screw box | - |
| VGA holder | - |
| VGA holder for inverted layout | - |
| Mesh Front Panel | - |
| ODD Bracket | - |
| Fan / Radiator bracket for multi mounting panel | - |
| Removeable dust filters | |
| Top | 1 |
| Front | 1 |
| Side | - |
| Bottom | 1 |
| Material | |
| Top cover | Steel |
| Front panel | ABS |
| Side panel | Steel |
| Side panel window | Glass |
| Stands | ABS |
| Safety certification | |
| Approvals | CE, UKCA |
| Environmental directives | |
| RoHS | √ |
| Reach | 1 |
| WEEE | √ |
| Triman | √ |
| Service | |
| Warranty (Years) | 3 |
| International hotline / free of charge | √ / DE, FR, US |
| Logistics data and RRP | |
| Article number | BGW77 |
| EAN code | 4260052192849 |
| Dimensions, package (L x W x H), (mm) | 518 x 292 x 503 |
| Gross weight, package (kg) | 9.2 |
| Pieces per packaging unit | 1 |
