Q7, 28.2mm Height, 125W TDP, Copper CPU Cooler
Quantity:
- SKU: 16160281
- Manufacturer: DYNATRON
- MPN: Q7
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$35.31
Q7, 28.2mm Height, 125W TDP, Copper CPU Cooler
The Dynatron Q7 CPU cooler is designed for Q7- 1U VC+ Blower
The Dynatron Q7 CPU cooler is designed for Q7- 1U VC+ Blower
| CPU Support | Intel® |
| CPU Socket | LGA 1700 |
| Solution | 1U Server and Up |
| Dimensions | 95 x 94 x 28.2 mm LWH |
| Weight | 380 g |
| Material | Copper Vapor Chamber Heatsink with Stacked Fins |
| Fan Dimension | Ø80 x 13 mm |
| Speed |
At Duty Cycle 20%: 2000 ± 200 RPM At Duty Cycle 50%: 4900 ± 10% RPM At Duty Cycle 100%: 8700 ± 10% RPM |
| Power |
At Duty Cycle 20%: 1.08 W At Duty Cycle 50%: 4.70 W At Duty Cycle 100%: 26.25 W |
| Bearing | Ball Type, Double |
| Rated Voltage | 12V |
| Air Flow |
At Duty Cycle 0~20%: 6.41 CFM At Duty Cycle 50%: 15.26 CFM At Duty Cycle 100%: 26.25 CFM |
| Noise Level |
At Duty Cycle 20%: 23.3 dBA At Duty Cycle 50%: 43.5 dBA At Duty Cycle 100%: 62.2 dBA |
| Air Pressure |
At Duty Cycle 20%: 3.69 mm-H2O At Duty Cycle 50%: 25.28 mm-H2O At Duty Cycle 100%: 89.80 mm-H2O |
| Lead Wire Pin Out |
Pin1- (-) Pin2- (+) Pin3- (Techometer/Signal output) Pin4- (PWM) |
