- Backplane support for 4 port SAS / SATA drives and 12 Gb/s Mini-SAS SFF-8087***
- Supports four 2.5" / 3.5" SAS/SATA HDD / SSD
- Includes three 80 x 15mm PWM fans
- Independent drive status LED
- Supports Micro ATX motherboards
- Supports four low profile PCI / PCIe slots
- Auto lock handle design easily secures to rackmount cabinet without screws
Model No. | SST-RM21-304 | |
Drive Bay | External | 3.5" or 2.5" HDD/SSD hot-swap x 4 |
Internal | 3.5" or 2.5" HDD/SSD hot-swap x 4 | |
3.5" Internal
|
-- | |
2.5" Internal | -- | |
Expansion Slot | Low profile PCI / PCIe x 4 | |
Power Supply | 2U single or 2U redundant / PS2 (ATX) up to 160mm deep and 86.3mm height (not included) | |
Dimension | 430mm (W) x 88.5mm (H) x 480mm (D) 18.3 Liters | |
Front buttons | Power On / Off, system reset | |
HDD backplane | 4 ports SAS / SATA to Mini-SAS SFF-8087 x 1 | |
HDD | SAS-1 / SAS-2 / SAS-3 | |
Interface | SATA-1 / SATA-2 / SATA-3 | |
Limitation of CPU cooler | 68mm | |
Motherboard | Micro ATX (9.6" x 9.6"), Mini-ITX (6.7” x 6.7”) | |
Power connector on HDD backplane | 4-Pin peripheral x 2 | |
Front I/O Port | USB 2.0 x 1, USB 3.1 Gen 1 Type-A x 1** | |
Net Weight | 6.3 kg | |
Chassis form factor | 2U | |
Indicators |
Chassis : Power LED x 1: Blue HDD Access x 1: Green LAN LED x 2: Green HDD Tray : HDD Power LED x 8: Yellow HDD Access x 8: Blinking green |
|
Main metal thickness | 1mm |
