Model
|
RocketU 1411C |
Host Bus Interface |
4-lane, 8 GT/s PCI Express 3.0 Compliant |
Interface Technology |
Supports up to USB 3.2 20Gb/s link speed. Backwards compatible with USB 3.x / 2.0 |
Supported Standard |
xHCI (eXtensible Host Controller Interface); UASP (USB attached SCSI protocol) |
Operating System Support (Mac compatibility) |
Not supported |
Operating System Support (Windows compatibility) |
Windows 11,10,8.1, Windows Server 2022, 2016, 2012, 2008 (64-bit editions), Compatible with PCIe slots |
Operating System Support (Linux compatibility) |
Linux kernel 3.10.0 and later, Compatible with PCIe slots |
Operating System Support (VMware ESXi compatibility) |
Yes |
Thunderbolt PCIe Expansion System Compatibility |
Supports USB 3.x devices when card is installed in a Thunderbolt to PCIe Card Expansion System |
Number of Channel / Port |
1 |
Port Type |
USB Vertical Type-C |
Data Transfer Rates |
20Gb/s per port |
Number of Devices |
1 x USB 3.x / 2.0 / 1.x compatible devices |
USB port Amperage |
1.5A output per port |
Bus Powered Peripherals |
Up to 7.5W per port for device operation or charging |
External Power Support |
N/A |
USB Port Sharing |
Dedicated (Not Shared): Each USB Port has a dedicated controller |
Form Factor |
Low-Profile |
Cooling system |
N/A |
Dimensions |
3.13"W x 2.56"H x 0.82"D |
Weight |
0.42 lbs. |
Warranty |
2 Years |
Compliance Certification |
CE, FCC, RoHS, REACH, WEEE |
Storage Features
|
Bootable Drive support |
Yes (Linux, Mac) |
Drive hotplug support |
Yes |
Operating Environment
|
Work Temp |
5°C ~ 45°C |
Storage Temp |
40°C ~ 65°C |
Operating Voltage |
PCI-e: 12V, 3.3V |
Power |
Typical:1.56W |
MTBF (Mean Time Before Failure) |
920,585 Hours |
Kit Contents
|
Model |
RocketU 1411C |
Controller card |
1x Controller card |
Quick Installation Guide |
1x Quick Installation Guide |
Low Profile Bracket |
1x Low Profile Bracket |
