| Model No. | SST-SEH2-B |
| Material | Steel, plastic |
| Motherboard | SSI-EEB, SSI-CEB, Extended ATX, ATX, Micro-ATX, Mini-ITX |
| Drive bay |
Internal
|
| Cooling system |
Front
Rear
Top
Side
|
| Radiator support |
Front
Rear
Top
Side
|
| Limitation of CPU cooler | 188mm |
| Expansion slot | 8 |
| Limitation of expansion card |
Length: 428.9mm (with front 25mm thickness fans installed) 330mm (with side radiator & fans installed) |
| Power supply | Standard PS2 (ATX) |
| Limitation of PSU | 220mm |
| Front I/O port |
USB Type-C x 1 USB 3.0 x 2 Combo Audio x 1 |
| Dimension |
244.9mm (W), x 528.3mm (H), x 543.2mm (D), 70.28 liters 9.64" (W), x 20.8" (H), x 21.39" (D), 70.28 liters |
| Net weight | 15.2 kg |
| Remark | [1] 3.5"/2.5" combo drive trays are also mounted in this location but cannot coexist with the fans or radiators. |
