ThinkPad Ultra Dock 170W Docking Station
- SKU: 8084058
- Manufacturer: LENOVO
- MPN: 40A20170US
- Availability: TEMPORARILY OUT OF STOCK
With the horsepower to drive mobile workstations, the completely re-designed and supercharged ThinkPad Ultra Dock with an included ThinkPad 170W AC Adapter grows capability without growing in size. The ultimate docking solution includes a wide range of video outputs, including HDMI 1.4, and support for multiple external monitors so you can multi-task like never before.3x USB 2.0, one supports always-on USB charging 3x USB 3.0 10/1000 Gigabit Ethernet, supports enterprise manageability 2x DisplayPort 1.2 1x DVI-D 1x HDMI 1.4 1x VGA Driver-free, perfect video quality 1x Stereo/Mic Combo Audio Port Charges your ThinkPad with an included ThinkPad 90W AC Adapter Physical rear alignment for a perfect dock every time Smaller desktop footprint vs. Series 3 docking stations Comes with ThinkPad AC adapter (170W) Some of the video ports do have exclusive use and are also dependent on the docked ThinkPad configuration
| Ports | 3 x USB 2.0 * ports
3 x USB 3.0 ports 10/1000 Gigabit Ethernet port 2 x DisplayPort 1.2** ports 1 x DVI-D** port 1 x HDMI 1.4** port 1 x VGA** port 1 x stereo/mic combo audio port |
| Hardware Compatibility | ThinkPad T440, T440s (all machine types and integrated graphics models only)
ThinkPad T440p, T540p, X240, W540 (all machine types and all models) |
| Certifications | EC DOC/S-DOC, CB, CE, UL, FCC, AS/NZS S-DOC, VCCI, BSMI, KCC, NOM, GOST, and UkrSEPRO |
| Operating Temperature | 41 to 109°F (5 to 43°C) |
| Operating Relative Humidity | 8 to 95% (non condensing) |
| Storage Temperature | -4 to 140°F (-20 to 60°C) |
| Storage Relative Humidity | 5 to 95% (non condensing) |
| Dimensions (W x H x D) | 13.58 x 2.19 x 6.40" (344.93 x 55.62 x 162.56 mm) Approx. |
| Weight | 2.03 lb (0.92 kg) Approx. |
| Package Weight | 4.35 lb |
| Box Dimensions (LxWxH) | 15.0 x 8.4 x 3.6" |
