PERFORMANCE | |
Processor |
Intel® Core™ i9-12900K, 16C (8P + 8E) / 24T, Max Turbo up to 5.2GHz, P-core 3.2 / 5.1GHz, E-core 2.4 / 3.9GHz, 30MB
|
Processor Sockets |
1x FCLGA1700
|
Integrated Graphics |
Integrated Intel® UHD Graphics 770
|
Discrete Graphics |
None
|
Chipset |
Intel® W680 Chipset
|
Memory |
32GB UDIMM DDR5-4400 Non-ECC
|
Memory Slots |
Four DDR5 UDIMM slots, dual-channel capable
|
Max Memory |
Up to 128GB (4x 32GB DDR5 UDIMM)
|
PCIe NVMe Controller |
Onboard Intel® RSTe PCIe®
|
PCIe NVMe Drive |
1x 1TB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal
|
SATA Controller |
Onboard Intel® RST SATA RAID
|
SATA/SAS Drive |
None
|
Storage Support |
Up to 2x 3.5" SATA HDD or 4x 2.5" SATA HDD; also supports up to 3x M.2 SSD (2 by onboard, 1 by M.2 to PCIe® adapter ) • 3.5" HDD up to 4TB each • 2.5" HDD up to 1TB each • Onboard M.2 SSD up to 4TB
each • M.2 SSD by M.2 to PCIe adapter up to 2TB
|
Optical |
None
|
Audio Chip |
High Definition (HD) Audio, Realtek® ALC897Q-CG codec
|
Power Supply |
750W Platinum Fixed
|
DESIGN | |
Keyboard |
USB Traditional Keyboard, Black, English
|
Mouse |
USB Calliope Mouse, Black
|
Expansion Slots |
Supports four PCIe® slots with two PCIe 4.0 x16 and two PCIe 3.0 x1. • Slot 1: PCIe 4.0 x16, full height, full length, 75W, double-width • Slot 2: PCIe 3.0 x1, full height, half length, 25W • Slot 3:
PCIe 4.0 x16 (x4 lanes), full height, half length, 25W • Slot 4: PCIe 3.0 x1, full height, half length, 25W
|
M.2 Slots |
|
Bays |
|
Dimensions (WxDxH) |
170 x 315.4 x 376 mm (6.7 x 12.4 x 14.8 inches)
|
Weight |
9.67 kg (21.32 lbs, maximum configuration)
|
CONNECTIVITY | |
Onboard Ethernet |
Intel® I219-LM, 1x GbE RJ-45
|
Optional Ethernet |
None
|
WLAN + Bluetooth |
None
|
Card Reader |
SD Card Reader
|
Front Ports |
|
Rear Ports |
|
Optional Rear Ports (configured) |
1x DP (Flex IO)
|
SECURITY & PRIVACY | |
Security Chip |
Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
|
Physical Locks |
|
Cover Lock |
None
|
Cable Lock |
No Cable
|
Chassis Intrusion Switch |
None
|
MANAGEABILITY | |
System Management |
Intel® vPro® Enterprise with Intel AMT 16
|
SERVICE | |
Base Warranty |
3-year, Onsite
|
Included Upgrade |
3Y Premier Support Upgrade from 3Y Onsite
|
Green Certifications |
|
ISV Certifications |
Please visit ISV certifications for Lenovo® Workstations
|
Mil-Spec Test |
MIL-STD-810H military test passed
|
SOFTWARE | |
Operating System |
Windows® 11 Pro, English
|
Bundled Software |
None
|
