Essentials |
Product Collection |
Intel® Wi-Fi 6 Series |
Code Name |
Products formerly Cyclone Peak |
Status |
Launched |
Launch Date |
Q2'19 |
Weight (in grams) |
2.83 |
Operating Temperature Range |
0°C to 80°C |
Operating Temperature (Maximum) |
80 °C |
Operating Temperature (Minimum) |
0 °C |
Supported Operating Systems |
Windows 11, 64-bit*, Windows 10, 64-bit*, Linux* |
Antenna |
2x2 |
Networking Specifications |
TX/RX Streams |
2x2 |
Bands |
2.4, 5 GHz (160MHz) |
Max Speed |
2.4 Gbps |
Wi-Fi CERTIFIED* |
Wi-Fi 6 (802.11ax) |
Compliance |
FIPS, FISMA |
Bluetooth Version |
5.2 |
Integrated Bluetooth |
Yes |
Package Specifications |
Board Form Factor |
M.2 2230 |
Package Size |
22mm x 30mm x 2.4mm |
System Interface Type |
Wi-Fi(PCIe), BT(USB) |
Advanced Technologies |
MU-MIMO |
Yes |
Supported Under Intel vPro® Technology |
No |
Orthogonal Frequency-Division Multiple Access (OFDMA) |
Yes |
