Status |
Launched |
Launch Date |
Q1'16 |
Processor Number |
E5-2697V4 |
Intel® Smart Cache |
45 MB |
Intel® QPI Speed |
9.6 GT/s |
# of QPI Links |
2 |
Instruction Set |
64-bit |
Instruction Set Extensions |
AVX 2.0 |
Embedded Options Available |
No |
Lithography |
14 nm |
Scalability |
2S |
VID Voltage Range |
0 |
Conflict Free |
Yes |
# of Cores |
18 |
# of Threads |
36 |
Processor Base Frequency |
2.3 GHz |
Max Turbo Frequency |
3.6 GHz |
TDP |
145 W |
Max Memory Size (dependent on memory type) |
1536 GB |
Memory Types |
DDR4 1600/1866/2133/2400 |
Max # of Memory Channels |
4 |
Max Memory Bandwidth |
76.8 GB/s |
Physical Address Extensions |
46-bit |
ECC Memory Supported ‡ |
Yes |
Processor Graphics ‡ |
None |
PCI Express Revision |
3.0 |
PCI Express Configurations ‡ |
x4, x8, x16 |
Max # of PCI Express Lanes |
40 |
Max CPU Configuration |
2 |
TCASE |
79°C |
Package Size |
52.5mm x 51mm |
Sockets Supported |
FCLGA2011-3 |
Low Halogen Options Available |
See MDDS |
Intel® Turbo Boost Technology ‡ |
2.0 |
Intel® vPro Technology ‡ |
Yes |
Intel® Hyper-Threading Technology ‡ |
Yes |
Intel® Virtualization Technology (VT-x) ‡ |
Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ |
Yes |
Intel® VT-x with Extended Page Tables (EPT) ‡ |
Yes |
Intel® TSX-NI |
Yes |
Intel® 64 ‡ |
Yes |
Idle States |
Yes |
Enhanced Intel SpeedStep® Technology |
Yes |
Intel® Demand Based Switching |
Yes |
Thermal Monitoring Technologies |
Yes |
Intel® Flex Memory Access |
No |
Intel® Identity Protection Technology ‡ |
No |
Intel® AES New Instructions |
Yes |
Secure Key |
Yes |
OS Guard |
Yes |
Trusted Execution Technology ‡ |
Yes |
Execute Disable Bit ‡ |
Yes |
