Xeon® w5-2545 12-Core 3.5 - 4.7GHz Turbo, LGA 4677, 252W MTP, OEM Processor
Quantity:
- SKU: 17995941
- Manufacturer: INTEL
- MPN: PK8071305502200
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$1,013.98
| Code Name | Products formerly Sapphire Rapids |
| Vertical Segment | Workstation |
| Processor Number | w5-2545 |
| Lithography | Intel 7 |
| CPU Specifications | |
| Total Cores | 12 |
| # of Performance-cores | 12 |
| # of Efficient-cores | 0 |
| Total Threads | 24 |
| Max Turbo Frequency | 4.7 GHz |
| Intel® Turbo Boost Max Technology 3.0 Frequency | 4.7 GHz |
| Intel® Turbo Boost Technology 2.0 Frequency‡ | 4.5 GHz |
| Processor Base Frequency | 3.5 GHz |
| Cache | 30 MB Intel® Smart Cache |
| Intel® UPI Speed | 0 GT/s |
| Max # of UPI Links | 0 |
| Processor Base Power | 210 W |
| Maximum Turbo Power | 252 W |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Supplemental Information | |
| Marketing Status | Launched |
| Launch Date | Q3'24 |
| Embedded Options Available | No |
| Use Conditions | Workstation |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 2 TB |
| Memory Types | DDR5-4800(MT/s) |
| Maximum Memory Speed | 4800 MHz |
| Max # of Memory Channels | 4 |
| Intel® Optane™ Persistent Memory Supported | No |
| ECC Memory Supported | Yes |
| Expansion Options | |
| Direct Media Interface (DMI) Revision | 4 |
| Scalability | 1S Only |
| PCI Express Revision | 5 |
| Max # of PCI Express Lanes | 64 |
| Package Specifications | |
| Sockets Supported | FCLGA4677 |
| Package Carrier | E1B |
| Max CPU Configuration | 1 |
| DTS Max | 100 °C |
| TCASE | 74 °C |
| Package Size | 77.5mm x 56.5mm |
| Advanced Technologies | |
| Intel® QuickAssist Technology (QAT) | 0 default devices |
| Intel® Dynamic Load Balancer (DLB) | 0 default devices |
| Intel® Data Streaming Accelerator (DSA) | 1 default devices |
| Intel® In-memory Analytics Accelerator (IAA) | 0 default devices |
| Intel® Advanced Matrix Extensions (AMX) | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Max Technology 3.0 | Yes |
| Intel® Turbo Boost Technology | 2 |
| Intel® Hyper-Threading Technology | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1 | Intel® AMX | Intel® SSE4.2 | Intel® AVX2 | Intel® AVX-512 |
| # of AVX-512 FMA Units | 2 |
| Enhanced Intel SpeedStep® Technology | Yes |
| Security & Reliability | |
| Intel vPro® Eligibility | Intel vPro® Enterprise |
| Intel® Software Guard Extensions (Intel® SGX) | No |
| Intel® Threat Detection Technology (TDT) | No |
| Intel® Active Management Technology (AMT) | Yes |
| Intel® Remote Platform Erase (RPE) | No |
| Intel® One-Click Recovery | No |
| Intel® QuickAssist Software Acceleration | No |
| Intel® Control-Flow Enforcement Technology | Yes |
| Intel® Total Memory Encryption - Multi Key | No |
| Intel® Total Memory Encryption | Yes |
| Intel® AES New Instructions | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® OS Guard | Yes |
| Intel® Boot Guard | Yes |
| Mode-based Execute Control (MBEC) | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
